This guide could help your NEM-Symbol blockchain node to migrate from symbol-bootstrap container (discontinued) to symbol shoestring container (python3 module container).
DISCLAIMER
This procedure takes no responsibility on your wallet keys custodial
or any losses of XYM.
Funds key is referred hereafter as “Main key” or “Wallet key”,
it should be stored safely offline.
The procedure described here deletes “Main key” with rm command
at section “Removing plain keys for node safety”.
PREREQUISITES:
- GNU/Linux Operating System
- a running symbol-bootstrap blockchain node
WHAT YOU WILL GET:
a NEM-Symbol blockchain node running on shoestring with latest catapult client version v1.0.3.8 using the same public key, the same node public key, the same remote key, the same vrf key as your existing symbol-bootstrap node.
PYTHON AND SHOESTRING INSTALLATION
Install pyenv and python
curl -fsSL https://pyenv.run | bash
echo 'export PYENV_ROOT="$HOME/.pyenv"' >> ~/.bashrc
echo '[[ -d $PYENV_ROOT/bin ]] && export PATH="$PYENV_ROOT/bin:$PATH"' >> ~/.bashrc
echo 'eval "$(pyenv init - bash)"' >> ~/.bashrc
exec "$SHELL"
pyenv install 3.11.12
pyenv global 3.11.12
python3 --version
for more information on this step check here https://github.com/pyenv/pyenv?tab=readme-ov-file#installation
Install Shoestring
pip install symbol-shoestring
pip show symbol-shoestring
You should have installed Shoestring Version: 0.2.1
For more information check here
https://qiita.com/ccHarvestasya/items/1c1a60beaf3a80d912c2
https://catnotes.xyz/symbol/best-practices/python-new-project
FIND YOUR NODE KEYS
NEM-Symbol blockchain client keys
To run your node you need four keys, one for each of these four types:
- Wallet (also known as
mainorca.key.pem) - Node (also known as
transport) - Remote (the remote harvesting key is the one Wallet is linked to)
- VRF (for Verifiable Random Function)
For more information check here
https://catnotes.xyz/symbol/transactions/understanding/links
Find the keys in bootstrap
Change directory to your symbol-boostrap node installation directory.
Your symbol-bootstrap installation directory now on is referred here as .
where you find the ./target directory and the ./target/addresses.yml file.
The keys mentioned before are written in addresses.ymlfile, immediately after these respective yml lines
main:
privateKey: ...
publicKey: ...
address: ...
transport:
...
remote:
...
vrf:
...
Please check with the NEM-Symbol blockchain mainnet explorer at
https://symbol.fyi that the ADDRESS of the main key is linked
with the remote public key and the vrf public key. Also check the xym balance.
You’ll need to decrypt them if they are ENCRYPTED, with this command
symbol-bootstrap decrypt --source target/addresses.yml --destination target/d_addresses.yml
enter the password, now you have decrypted keys in your bootstrap node directory under ./target/d_addresses.yml
Copy the keys to shoestring node directory
Now create a new shoestring node directory (check you don’t have it already)mkdir -p ../shoestring-node
copy the keys there
grep -A1 main d_addresses.yml | sed -nE 's/[[:space:]]*privateKey:[[:space:]]*//p > ../shoestring-node/main_k.txt
grep -A1 transport d_addresses.yml | sed -nE 's/[[:space:]]*privateKey:[[:space:]]*//p > ../shoestring-node/transport_k.txt
grep -A1 remote d_addresses.yml | sed -nE 's/[[:space:]]*privateKey:[[:space:]]*//p > ../shoestring-node/remote_k.txt
grep -A1 vrf d_addresses.yml | sed -nE 's/[[:space:]]*privateKey:[[:space:]]*//p > ../shoestring-node/vrf_k.txt
Special case for voting keys
For voting keys we just have dat files. We copy all of them.
cp ./target/nodes/node/votingkeys/private_key*.dat ../shoestring-node
That’s all the keys, but we need the wallet address too so execute alse
grep -A3 main d_addresses.yml | sed -nE 's/[[:space:]]*address:[[:space:]]*//p > ../shoestring-node/main_a.txt
NOTE:
The main key should not stay on your online host for security reasons.
Find your way to store offline the main key. Voting nodes have this key
being the 3M XYM wallet (could be also a multisig wallet).
The remote key is the key used for node harvesting, it is linked to your
main wallet. Your node could not harvest if this key is lost. Backup remote, and VRF accordingly.
CREATE SHOESTRING NODE ON THE SAME KEYS
Change directory to shoestring node created beforecd ../shoestring-node
Generate and edit init file
python -m shoestring mainnet.ini --package mainnet
vi mainnet.ini
Edit [node] section
Choose features accordingly or leave it there.
Give a value to caCommonName i.e. caCommonName = myhost.com
Give a value to nodeCommonName i.e. nodeCommonName = node
Generate ovverrides.ini
printf "[node.localnode]\n" > overrides.ini
printf "host = "$(hostname) >> overrides.ini
printf "\nfriendlyName = friendlyname" >> overrides.ini
substitute friendlyname with your node friendly name at wish.
Generate the ca.key.pem
This the certificate contains your wallet key. Voting nodes should
have 3M xym balance in it. It is generated from main_k.txt
and will be deleted from the filesystem because it should not stay
online for security reasons.
python -m shoestring pemtool --input ./main_k.txt --output ./ca.key.pem
This command has generated the file ca.key.pem
Generate the node.key.pem
This certificate is the node transport and should be rotated for security reasons but in this article we want a clone of our bootstrap node so we reuse the same transport by generating it from the transport key.
python -m shoestring pemtool --input ./transport_k.txt --output ./node.key.pem
We update the config file to instruct to use this transport key
sed -i 's%nodeKey = %& '$PWD'/node.key.pem%' mainnet.ini
You can check that the public key corresponds to your node in https://nemnodes.org/nodes with the value in the last column of your node’s row, called node publi key, with the output of this command.openssl pkey -in node.key.pem -pubout -noout -text
Create shoestring setup
python -m shoestring setup --package mainnet --ca-key-path ./ca.key.pem --config ./mainnet.ini --overrides ./overrides.ini --directory .
Override remote harvesting key
This setup has generated a new harvesting key so we need to ovverride it using our remote key. We delete the linking transaction and we overwrite the remote key with the one we copied from bootstrap.
rm linking_transaction.dat
python -m shoestring pemtool --input remote_k.txt --output ./keys/remote.pem
cat remote_k.txt | xargs -I{} sed -iE 's/(harvesterSigningPrivateKey = )(.*$)/\1'{}'/' ./userconfig/resources/config-harvesting.properties
Override VRF key
python -m shoestring pemtool --input vrf_k.txt --output ./keys/vrf.pem
cat vrf_k.txt | xargs -I{} sed -iE 's/(harvesterVrfPrivateKey = )(.*$)/\1'{}'/' ./userconfig/resources/config-harvesting.properties
Update beneficiary address
cat main_a.txt | xargs -I{} sed -iE 's/(beneficiaryAddress =)(.*$)/\1 '{}'/' ./userconfig/resources/config-harvesting.properties
Please check that config-harvesting.properties file content has the correct values of our private keys
harvesterSigningPrivateKey = #should have the value of the remote private key
harvesterVrfPrivateKey = #should have the value of the vrf private key
beneficiaryAddress = #should have the address of our wallet (3M for voting nodes)
Override voting keys
rm -rf ./keys/voting/private_key_tree1.dat
mv private_key_tree*.dat ./keys/voting/
The setup is completed.
Next step should be:
Shut down bootstrap node
Start up shoestring node from the shoestring directory
eventually clean docker with prune system -a
Remember to delete the keys once the node is functioning well
this means to delete these files after having made an offline backup
target/d_addresses.yml
shoestring_node/main_k.txt
shoestring_node/transport_k.txt
shoestring_node/remote_k.txt
shoestring_node/vrf_k.txt
shoestring_node/ca.key.pem
shoestring_node/node.key.pem
CREDITS
Greetings to dusanjp.com and his samdal network that made possible to have sperimental activity
